SYSMEX CA-500 - Page 186

CA-500 Series S/M A-1-9 Revised October 2003
17 ECR303G037
CA-500 Chassis Assy (2/2)
Code No. Drawing
No.
Description Qty per
Unit
663-0161-0 1 COOLING SECTION ASSY 1
663-0217-1 2 TABLE LOCK MECHANISM ASSY 1
663-0199-1 3 RINSING CUP ASSY 1
663-0158-8 4# DETECTOR BLOCK (AT3) 1
663-0159-1 4* DETECTOR BLOCK (STANDARD) 1
8
663-0399-1 4& DETECTOR BLOCK (D-DIMER) 1
17
663-0415-4 4&& DETECTOR BLOCK (D-DIMER 800NM) 1
322-9151-5 5 TRASH COVER CA-500 1
663-0201-1 6 X AXIS MOTOR ASSY 1
662-0220-5 7 PCB NO.4086 1
289-9377-2 8 SW REGULATOR LCA150S-12 1
289-9376-9 9 SW REGULATOR LCA50S-5 1
A
289-9378-6 10 SW REGULATOR LCA150S-24-XJCM 1
A
289-9379-0 10 SW REGULATOR LCA150S-24-H 1
662-8182-0 11 X AXIS WIRING CORD 1
662-0224-0 12 PCB NO.9260 1
662-2207-3 13 THERMAL SENSOR ASSY 1
#: CA-530, CA-540
*: CA-510, CA-520
&: CA-550, CA-560
&&: CA-550, CA-560 (800nm detector block)
