CA-500 Series S/M A-1-11 Revised October 2003
CA-500 Detector Block 8
Code No. Drawing
No.
Description Qty per
Unit
663-0159-1 1-5* DETECTOR BLOCK (STANDARD) 1
663-0158-8 1-6# DETECTOR BLOCK (AT3) 1
663-0399-1 1-8& DETECTOR BLOCK (D-DIMER) 1
17
663-0415-4 1-8$ DETECTOR BLOCK (D-DIMER 800NM) 1
662-0217-3 1*# PCB NO.2132 (STANDARD) 1
662-0281-2 1*# PCB NO.2156 (STANDARD CLOT/AT3) 1
662-0285-7 1& PCB NO.2156 (5 CIRCUITS DD 575NM) 1
17
662-0284-3 1$ PCB NO.2156 (4 CIRCUITS DD 800NM) 1
662-2205-6 2 COAGULATION LED ASSY 1
662-0218-7 3* PCB NO.2132 (2 CIRCUITS) 1
662-0282-6 3* PCB NO.2156 (2 CIRCUITS CLOT) 1
662-0219-1 3# PCB NO.2132 (3 CIRCUITS) 1
17
662-0283-0 3#&$ PCB NO.2156 (3 CIRCUITS AT3/DD) 1
662-2203-9 4 DETECTOR THERMAL ASSY 1
663-0160-6 5 HEATER ASSY 1
17
662-2204-2 6#&$ CHROMOGENIC LED ASSY 1
662-0280-9 7& D-DIMER LED ASSY (575NM) 1
17
662-0279-4 7$ D-DIMER LED ASSY (800NM) 1
17
663-0404-3 8&$ CH6 10
266-5395-2 9 FUSE THERMAL 125V5A TYPE210 10
662-8214-1 10 WIRING CORD PD DW0458 1
* : CA-510, CA-520
# : CA-530, CA-540
& : CA-550, CA-560
$ : CA-550, CA-560 (800nm detector block)
: PCB used with CA-550/560 (upper compatible), and will be replaced with the old PCB (written
above) when the stock is depleted.
ECR, TB No Serial No.
8
200203 CA-550 A1001-, CA-560 A1001-
17
303G037 Not applicable
