SYSMEX CA-500 - Page 190

CA-500 Series S/M A-1-13 Revised June 2003
14 ECR303C033
CA-500 Cooling Section Assy
Code No. Drawing
No.
Description Qty per
Unit
663-0161-0 1- COOLING SECTION ASSY 1
B
663-0162-3 1 COOLER ASSY (THERM
A
L MODULE) 1
14
663-0163-7 2 COOLING FAN ASSY 1
662-2206-0 3 COOLER THERMAL ASSY (SERNSOR IC) 1
426-3152-0 4 SILICONE GREASE THERMAL 800-8 1
A
348-5936-2 5 SCREW ROUND M3X15 PC(+) 100
C
663-0372-1 6 HEAT SINK DM1113 1
A 399E018 - -
B 399J015 CA-510 A1030-, CA-520 A1003-, CA-530 A1393-, CA-540 A2277-
C 399K012 - - -
14 ECR303C033
