TABLE LOCK MECHANISM ASSY & X AXIS SLIDER ASSY
Code No. Drawing
No.
Description Qty per Unit
663-0217-1 1- TABLE LOCK MECHANISM ASSY 1
663-0200-8 1 SOLENOID ASSY 1
228-3753-3 2 PHOTO-INTERRUPTER LG-217D-3 1
663-0181-4 11- X AXIS SLIDER ASSY 1
663-0185-9 11 Y AXIS MOTOR ASSY 1
A
342-1816-4 12 TIMING BELT B488MXL9.5 1
CA-500 Series S/M A-1-15 Revised December 2001 8
