CA-500 Series S/M A-1-17 Revised March 2003
12 303A066
2 200049
CA-500 Z Axis Base Assy
Code No. Drawing
No.
Description Qty per
Unit
663-0182-8 1- Z AXIS BASE ASSY 1
663-0183-1 1 PIPETTE HOLDER ASSY 1
663-0188-0 2 CATCHER ASSY 1
663-0186-2 3 Z AXIS MOTOR ASSY 1
662-0222-2 4 PCB NO.9264 1
228-4050-8 5 PHOTO-IC SENSOR PS-R11L 1
663-0189-3 6 TUBING ASSY (PIPETTE) 1
A
324-9078-4 7 CATCH BOX DM1357 1
A
324-9076-7 8 CATCH HOLD PLATE DM1358 1
A
342-1815-1 9 TIMING BELT B216MXL4.8 1
2
663-0393-0 10 Z1 SLIDER-C ASSY DU1469 1
2
663-0394-3 11 Z2 SLIDER-C ASSY DU1468 1
12
322-9152-9 12 ZSB REAR COVER 1
