SYSMEX CA-500 - Page 208

CA-500 Series S/M A-1-31 Revised June 2003
RINSE BOTTLE ASSY & WASTE BOTTLE ASSY
Code No. Drawing
No.
Description Qty per Unit
663-0209-1 1-8* RINSE BOTTLE ASSY CA-5H (2L) 1
8
663-0407-4 1-8# RINSE BOTTLE ASSY CA-5H (2L/EU/UK) 1
662-2220-2 1 RINSE BOTTLE FLOAT SWITCH ASSY (2L) 1
424-4679-6 2 LID NO. 9 5
424-9150-0 3 BOTTLE TANK-A (RINSE 2L/BLUE) 1
15
369-8604-6 4* INSTRUCTION LABEL-7 1
15
369-8326-1 4# CAUTION MARK NO.208 1
15
369-8601-5 5* INSTRUCTION LABEL-1 (JAPANESE) UNSALABLE
15
369-8326-1 5# CAUTION MARK NO.208 1
369-8016-8 6* CAUTION MARK NO. 16 1
664-0167-9 7 FILTER ASSY FOR RINSE BOTTLE 1
443-2804-4 8 NON-RETURN VALVE MFP-6-V 1
8
663-0402-6 11-18* RINSE BOTTLE ASSY CA-5H (5L) 1
8
663-0405-7 11-18# RINSE BOTTLE ASSY CA-5H (5L/EU/UK) 1
8
662-2409-1 11 RINSE BOTTLE FLOAT SWITCH ASSY (5L) 1
8
424-4679-6 12 LID NO. 9 5
15
663-0410-6 13-15* BOTTLE TANK (RINSE 5L/BLUE) 1
15
663-0411-0 13-15# BOTTLE TANK (RINSE 5L/BLUE/EU/UK) 1
15
369-8604-6 14* INSTRUCTION LABEL-7 1
15
369-8326-1 14# CAUTION MARK NO.208 1
15
369-8601-5 15* INSTRUCTION LABEL-1 (JAPANESE) UNSALABLE
15
369-8326-1 15# CAUTION MARK NO.208 1
8
369-8016-8 16* CAUTION MARK NO. 16 1
8
664-0167-9 17 FILTER ASSY FOR RINSE BOTTLE 1
8
443-2804-4 18 NON-RETURN VALVE MFP-6-V 1
663-0210-5 21-26* WASTE BOTTLE ASSY CA-5H (2L) 1
10
663-0408-8 21-26# WASTE BOTTLE ASSY CA-5H (2L/EU/UK) 1
662-2221-6 21 WASTE BOTTLE FLOAT SWITCH ASSY (2L) 1
424-4679-6 22 LID NO. 9 5
424-9151-3 23 BOTTLE TANK-A (WASTE 2L/RED) 1
15
369-8602-9 24* INSTRUCTION LABEL-2 1
15
369-8603-2 25* INSTRUCTION LABEL-3 (JAPANESE) UNSALABLE
369-8016-8 26* CAUTION MARK NO. 16 1
8
663-0403-0 31-36* WASTE BOTTLE ASSY CA-5H (5L) 1
10
663-0406-1 31-36# WASTE BOTTLE ASSY CA-5H (5L/EU/UK) 1
8
662-2410-6 31 WASTE BOTTLE FLOAT SWITCH ASSY (5L) 1
8
424-4679-6 32 LID NO. 9 5
15
663-0412-3 33-35* BOTTLE TANK (WASTE 5L/RED) 1
15
663-0413-7 33-35# BOTTLE TANK (WASTE 5L/RED/EU/UK) 1
15
369-8602-9 34* INSTRUCTION LABEL-2 1
15
369-8603-2 35* INSTRUCTION LABEL-3 (JAPANESE) UNSALABLE
8
369-8016-8 36* CAUTION MARK NO. 16 1
* : For 117V
# : For 220/240V
8 TB200203
10 ECR301K074
15 ECR303F001
