CA-500 Series S/M A-1-39 Added May 2002
CA-500 Pressure Chamber Kit (OPTION) 9
-
Code No. Drawing
No.
Description Qty per
Unit
021-0011-0 1- PRESSURE CHAMBER KIT CA-5H 1
365-1333-3 1 SUPPORT NO.247 1
443-0823-8 2 CHAMBER NO. 4 1
363-5015-0 3 FIXING MATERIAL NO. 15 1
363-1597-8 4 STAY NO.11 1
443-2804-4 6 NON-RETURN VALVE MFP-6-V 1
346-3939-1 8 O-RING P-39 10
346-3909-0 9 O-RING P- 8 (NITRIL) 10
348-5082-5 10 SCREW HEX-SOCKET BOLT M8X14(SU 50
348-3812-1 11 SCREW BINDING M3X6 (SUS) 100
442-5305-4 13 TUBE SILICONE 2 X 4MM SR-1554 1
442-5290-6 14 TUBE SILICONE 4MMID X 8MMOD 20
442-5475-1 15 TUBE TOALONE 3MMID X 6MMOD 10
461-9128-7 18 TRAP CHAMBER PROCEDURE 1
In the following CA instruments, the Pressure Chamber Kit has already installed.
CA-510 S/N A1023 and thereafter
CA-530 S/N A1368 and thereafter
CA-540 S/N A2016 and thereafter
