SYSMEX CA-500 - Page 219

ALPHABETICAL INDEX
CA-500 Series S/M A-3-2 Revised February 2004
19 TB200408
PARTS DESCRIPTION PART NO. UNIT Q'TY PAGE NO.
DETECTOR BLOCK (D-DIMER) 663-0399-1 1 A-1-11 1-8&
DETECTOR BLOCK (STANDARD) 663-0159-1 1 A-1-9 4*
DETECTOR BLOCK (STANDARD) 663-0159-1 1 A-1-11 1-5*
DETECTOR THERMAL ASSY 662-2203-9 1 A-1-11 4
DETECTOR THERMAL ASSY 662-2203-9 1 A-1-35 20
DRIVE ARM ASSY 663-0180-1 1 A-1-7 1
EMERGENCY STOP SW ASSY 663-0171-7 1 A-1-27 2
EMERGENCY STOP SW ASSY 663-0171-7 1 A-1-35 26
FILTER ASSY FOR RINSE BOTTLE 664-0167-9 1 A-1-31 7
8
FILTER ASSY FOR RINSE BOTTLE 664-0167-9 1 A-1-31 17
FIXING MATERIAL NO. 15 363-5015-0 1 A-1-39 3
FIXING MATERIAL NO.15 363-5015-0 1 A-1-36 3
19
FIXING SCREW TL-233 344-5471-7 1 A-1-33 14
5
FUSE 125V6A UL-TSC-6A-N1 266-5045-0 1 A-1-5 5$¥
FUSE 250V3.15A NO.19195(EUROP) 266-5293-0 10 A-1-5 5#
5
FUSE 250V6.3A ST4-6.3A-N1(N.A. 266-5106-0 1 A-1-5 5$¥
FUSE HOLDER CAP 031-1663(EUROP 266-3533-5 10 A-1-5 7#
FUSE HOLDER CAP 031-1666(N.AME 266-3536-6 10 A-1-5 7$¥
FUSE THERMAL 125V5A TYPE210 266-5395-2 10 A-1-11 9
C
HEAT SINK DM1113 663-0372-1 1 A-1-13 6
HEATER ASSY 663-0160-6 1 A-1-11 5
HEATER ASSY 663-0160-6 1 A-1-35 21
2
HINGE R-45 N GREASE TOA 344-3529-8 1 A-1-7 7
HOLDER NO. 89 363-2558-6 1 A-1-3 OPTION
HOLDER NO. 90 (TTO) 363-2559-0 1 A-1-3 OPTION
HYDRAULIC CONNECTOR NO.23 442-3433-7 10 A-1-5 15
2
ID ASSY 663-0177-9 1 A-1-3 10
ID ASSY 663-0177-9 1 A-1-35 9
ID MOTOR ASSY 663-0176-5 1 A-1-3 11
ID MOTOR ASSY 663-0176-5 1 A-1-35 8
ID WIRING CORD 662-8181-6 1 A-1-3 12
ID WIRING CORD 662-8181-6 1 A-1-35 7
15
INSTRUCTION LABEL-1 (JAPANESE) 369-8601-5 UNSALABLE A-1-31 5*
15
INSTRUCTION LABEL-1 (JAPANESE) 369-8601-5 UNSALABLE A-1-31 15*
15
INSTRUCTION LABEL-2 369-8602-9 1 A-1-31 24*
15
INSTRUCTION LABEL-2 369-8602-9 1 A-1-31 34*
15
INSTRUCTION LABEL-3 (JAPANESE) 369-8603-2 UNSALABLE A-1-31 25*
15
INSTRUCTION LABEL-3 (JAPANESE) 369-8603-2 UNSALABLE A-1-31 35*
15
INSTRUCTION LABEL-7 369-8604-6 1 A-1-31 4*
15
INSTRUCTION LABEL-7 369-8604-6 1 A-1-31 14*
14
INVERTER CXA-K05M-C 228-9153-2 1 A-1-25 4
14
INVERTER INV-5 228-9153-2 1 A-1-25 4
LCD LRHBJ3431A 228-3754-7 1 A-1-3 8
LCD LRHBJ3431A 228-3754-7 1 A-1-25 1
LID NO. 9 424-4679-6 5 A-1-31 2
8
LID NO. 9 424-4679-6 5 A-1-31 12
LID NO. 9 424-4679-6 5 A-1-31 22
8
LID NO. 9 424-4679-6 5 A-1-31 32
8
LIGHT SHIELD COVER ASSY 663-0204-2 1 A-1-3 13&
8
LIGHT SHIELD COVER ASSY (IMMUNO) 663-0401-2 1 A-1-3 13%
3
LOCK SPRING DM1298 324-9083-3 1 A-1-38 1
MAIN UNIT FAN ASSY 663-0196-0 1 A-1-5 23
MAIN UNIT FAN ASSY 663-0196-0 1 A-1-35 10
MIXER MOTOR ASSY 663-0187-6 1 A-1-19 2
MIXER MOTOR ASSY 663-0187-6 1 A-1-35 19
NIPPLE NO. 9 442-3509-2 10 A-1-21 11
