APPENDIX: B INSTALLATION
B.1 Check Before Installation
Based on the following check list, check the packings before installation.
B.1.1 Unpacking Check List
Table B-1: Unpacking Check List
Description Quantity Check
117V 220V 240V
461-2047-7 CA-500 Operator's Manual 1 1 1
266-5293-0 Fuse 250V 3.15A No. 19195 (Europe) - 2 2
266-5106-0 Fuse 250V 6.3A ST4-6.3A-N1 (N.Amer) 2 - -
663-0213-6 Holder CA-500 (for 13 mm diameter tube) 1 1 1
369-5982-2 Indication Mark No. 954 (for Reagent Rack) 1 1 1
462-4842-7 Paper Thermal F1-2 (2/Pack) 1 1 1
265-4719-0 Power Cord 4622-007-0092 (Europe) - 1 -
265-4723-5 Power Cord F1686 (U.K.) - - 1
793-0012-1 Power Cord No. 4 (N.Amer) 1 - -
541-1352-1 Push Vial PV-10 (22 mm OD x 40 mm high) 2 2 2
541-0541-8 Reaction Tube (CA-1000) 60 60 60
663-0206-0 Reagent Rack CA-500 1 1 1
663-0209-1 Rinse Bottle CA-500 Assembly 1 1 1
663-0407-4 Rinse Bottle CA-500 Assembly (EU/UK) 1 1 1
663-0402-6 Rinse Bottle CA-500 Assembly (5L)* 1 1 1
663-0405-7 Rinse Bottle CA-500 Assembly (5L) (EU/UK)* 1 1 1
833-3895-6 Sample Rack No. 3 w/Holder #55 1 1 1
663-0208-7 Sample Tube Rack CA-500 2 2 2
663-0211-9 Trap Chamber CA-500 Assembly 1 1 1
663-0207-3 Tube Trash CA-500 1 1 1
663-0210-5 Waste Bottle CA-500 Assembly 1 1 1
663-0403-0 Waste Bottle CA-500 Assembly (5L)* 1 1 1
*: Packed with CA-550/560
CA-500 Series S/M B-1 Revised December 2001 8
