DISPLAY AND CONTROL ELEMENTS 4
MHL380 D 4.63
4.10.12 Wiper water pump
In wiper mode, the windows are sprayed by
outlet nozzles (100/1) and (100/4) with wiper
water.
The "Wiper water pump (upper windshield)"
and/or optional "Wiper water pump (lower
windshield)" functions are performed when the
focus is on the symbol (99/102) and/or
(99/108) (washing water is sprayed through
the outlet nozzles) throughout the entire time
that the multi-function button (99/21) is
pressed.
After the multifunction button (99/21) has
been released, the windscreen wiper will con-
tinue to run for approximately 4 seconds.
In the end position, the windshield wiper is
kept in its position (100/3) such that it does
not flap into the cab when the windshield is
opened.
The wiper blade is fitted to the wiper arm
(100/3). A worn wiper blade should be re-
placed from inside the cab. To do this, slide
the windshield up and lock it.
The filler neck of the fluid container (101/1) for
the windshield washer is located on the rear
of the cab. The reservoir holds approx.
3.5 liters. We recommend that you always add
window cleaner containing antifreeze to the
water.
Fig. 100 Upper windshield wiper
Fig. 101 Filler neck for fluid container
