RECOVERY, LOADING, AND TRANSPORT 6
MHL380 D 6.1
6 Recovery, loading, and transport
6.1 Towing the machine
The loading machine may only be towed in
exceptional circumstances, for example to
move the machine away from a dangerous
location for repairs. Damage and accidents
that occur when towing the machine do not
fall under the warranty obligation of the manu-
facturer.
Rods that are used for towing must have suf-
ficient tensile strength and be fastened to the
towing lug (146/1) provided for this purpose at
the front or back of the undercarriage.
The towing lugs have a maximum bearing pres-
sure of 250 kN.
Danger of injury due to uncon-
trollable machine
The following values must not be
exceeded when towing:
• Towing speed:
max. 5 km/h
• Towing distance: max. 10 km
• With the diesel engine turned off
and the parking brake released,
all machine brakes are out of op-
eration and the steering is not
ready for operation.
In an emergency: Administer first
aid, seek treatment from a doctor
Danger of injury due to machine
rolling away
• Before work on the parking brake
or underneath the machine in
general commences the machine
must be secured with chocks so
that it cannot roll away.
In an emergency: Administer first
aid, seek treatment from a doctor
Before the loading machine can be towed, the
parking brake must be released and the two
propshafts must be decoupled and tied up on
the axle sides.
Fig. 146 Towing lug
Fig 147 Symbol
Towing
the
machin
