Terex Fuchs MHL380 D User Manual

5 WORK OPERATION
5.2 MHL380 D
5.1.1 ISO control system
 Current machine control unit (if yes, please tick)
MHL-XXXX-801
4
5
9
6
7
10
11
1216
13
17
14
18
15
19
20
21
22
23
8
2
1
3
Fig. 126 Assignment with ISO control system
1 Open grab
2
Raise boom
3
Close grab
4
Lower boom
5
Engine speed
6
Clockwise grab rotation
7
Extend dozer blade
1)
8
Rotate grab counterclockwise
9
Retract dozer blade
1)
1
0 Retract outrigger
1
1 Extend outrigger
1
2 Right indicator
13 Switch magnet system on/off
1)
1
4 Left indicator
1
5 Horn
1
6 Swing uppercarriage clockwise
1
7 Retract dipperstick
1
8 Swing uppercarriage anticlockwise
1
9 Extend dipperstick
2
0 Extend tilting cylinder
1)
2
1 Retract tilting cylinder
1)
2
2 Service brake
2
3 Travel direction FWD/REV
1)
Optional
5.1.1
ISO
control
system
