DISPLAY AND CONTROL ELEMENTS 4
MHL380 D 4.3
Overview of the display and control elements
10 Emergency lowering of cab
11 Lever for extending/retracting 4-point outrigger
12 Four-way control lever (left)
13 Upward folding armrest with switch (work functions disabled)
14 Foot button for boom float function (optional)
15 Pedal for extending/retracting tilting cylinder (optional)
16 Service brake pedal, lockable
17 Forward accelerator pedal (j
Note alignment of uppercarriage/undercarriage!)
18 Reverse accelerator pedal (j
Note alignment of uppercarriage/undercarriage!)
19 Steering column adjustment (inclination angle)
20 Four-way control lever (right)
21 Multifunction button
22 Magnet system control device (optional)
23 Multifunction display
24 Control panel
25 Operator device for supplementary heating (optional)
26 Lever with controller for heater/air conditioning system
27 Radio, CD player (optional)
28 Cooling/heating system for lunchbox/bottle holder
