APPENDIX 9
MHL380 D 9.1
9 Appendix
9.1 Arrangement of fuses
Danger of injury due to malfunctions
• Use only original fuses.
• Electrical fuses must never be bypassed or repaired.
In an emergency: Switch off machine, administer first aid, seek treat-
ment from a doctor
The following fuses and relays are located in the central electrical system (in the circuit diagram,
location:+03a):
Tripping cur-
rent intensity
-B54 Multifunction display
F 4 7.5 A Terminal 30 Side lights
Supplementary heating (optional)
Supplementary heating (optional)
Radio, socket, cigarette lighter, voltage converter, interior
lighting
Refueling pump (optional)
F 11 5 A Terminal 15 -B68 CR2016 Central electrical system +UB, optional -
B74 Fuchs Quick Connect (FQC), rear view camera
Tank sensor, throat depth stop limiting, dipperstick work
zone extension, loading height limiting, overload warning
device
-B47 CR2016 Undercarriage
-B64 Multifunction button
-B54 Multifunction display
F 17 10 A Terminal 15 Main window wiper, lower window wiper (optional)
-B11 Load limit sensing control
Four-way control lever (right/left)
F 22 5 A Terminal 15 Service ladder, grease lubrication system
-B35 CR0020 Main control, central electrical system con-
trol +UB D-Sub X3
Excitation voltage alternator D+, operating hours, joystick
steering (optional), particulate filter (optional)
F 26 7.5 A Terminal 15 Reserve, Emergency control K 14, K 15
