Terex Fuchs MHL380 D User Manual

9 APPENDIX
9.2 MHL380 D
Fuse
number
Tripping cur-
rent intensity
Terminal
designation
Functionality
F 27
10 A
Terminal 30
Reserve, optional: particulate filter
F 28
15 A
Terminal 30
Reserve
F 29
3 A
Terminal 30
EMR3 +UB, main relay K 2
F 30
25 A
Terminal 30
EMR3 Main relay K 2
F 31
5 A
Terminal 15
Power relay K 1
F 32
10 A
Terminal 15
-A1 Air conditioning system condenser
F 33
10 A
Terminal 15
-A1 Air conditioning system condenser
F 34
10 A
Terminal 15
-A1 Air conditioning system condenser
F 35
15 A
Terminal 15
-B47 CR2016 Undercarriage +UB, Group 1 and 2 outputs
F 36
15 A
Terminal 15
Blower for air conditioning system
F 37
30 A
Terminal 15
-A1 Air conditioning system condenser K 3
F 38
10 A
Terminal 15
-A1 Air conditioning system condenser K 4
F 39
10 A
Terminal 15
-B1 CR0303 VBBo 01-03
F 40
15 A
Terminal 15
Radio, voltage converter, operator's seat
F 41 10 A Terminal 15 Sensors: hydraulic oil return filter, hydraulic oil tempera-
ture, hydraulic oil level, open/close grab, travel, auto-idling
system, parking brake
F 42
10 A
Terminal 15
-B1 CR0303 Cab floor control
F 43
7.5 A
Terminal 15
Reserve, reversing fan mode (optional)
F 44
10 A
Terminal 15
-B68 CR2016 Central electrical system, outputs group 2,
optional: -B74 CR2016, outputs group 2
F 45
15 A
Terminal 15
-B35 CR0020 Main control
F 46
15 A
Terminal 15
Working headlamps, dipperstick
F 47 15 A Terminal 15 -B35 CR0020 Main controller
F 48
15 A
Terminal 15
Reserve switch cab, reserve
F 49
3 A
Terminal 15
High pressure filter, swivel
F 50
15 A
Terminal 15
Working headlamps, boom (optional)
F 51
7.5 A
Terminal 15
-B37 EMR3 Control device, air differential pressure
switch, EMR3 engine diagnostics plug
F 52
15 A
Terminal 15
-B68 CR2016 Central electrical system, outputs group 1
F 53
15 A
Terminal 15
Reserve
F 54 15 A Terminal 15 Cab protection ventilation (optional)
CR0020 Main control
CR0303
Cab floor control box
CR2016
Central electrical system 1 x standard, 1 x optional, 1 x optional undercar-
riage
