APPENDIX 9
MHL380 D 9.3
The fuses and relays below are located in the junction box in the engine compartment (in the cir-
cuit diagram, location: +04):
Fuse
Function
F1-Mega 100 A
Generator B+
F2-Mega 100 A
Preheat relay glow plugs
F3-Mega 100 A Terminal 30
F4-Midi 40 A
Ignition, diesel engine starter
Arrangement of the relays
Relay number
Functionality
Central electrical system (in the circuit diagram, location: +03)
K 1
Power relay terminal 15
K 84
Diesel engine starter
Central electrical system board (in the circuit diagram, location: 03a)
K 2
EMR3 Main relay (engine control unit)
K 3
Air conditioning condenser blower
K 4
Working headlamps, dipperstick (optional)
K 5
Working headlamps, boom (optional)
K 6 Optional: Fuchs Quick Connect (FQC)
K 8
Air conditioning system
K 9
Reserve
K 10
Tank sensor
K 11
Refueling pump (optional)
K 12 Reserve
K 13
Optional: Fuchs Quick Connect (FQC)
K 14
Emergency control
K 15
Emergency control
Engine compartment (in the circuit diagram, location: +04)
K 2
-
Control box, cab floor (in circuit diagram, location: +02c)
K 1 Wiper, main window
K 2
Lower window wiper (optional)
K 3
Air conditioning system
K 4
Air conditioning system
