4 DISPLAY AND CONTROL ELEMENTS
4.66 MHL380 D
4.11 Cab which can be raised and moved
forward hydraulically
The can can be variably elevated steplessly
up to a viewing height of 6.20 and inde-
pendently moveable by 2.20 m.
4.11.1 Before putting the machine into
operation
The cab's lifting equipment must undergo a
function test every day.
Serious injury due to sagging
cab
• The cab may only be repaired
whilst in the elevated position if
the lift frame is adequately sup-
ported.
In an emergency: Administer first
aid, seek treatment from a doctor
A sleeve may be affixed to the piston rod of
the lift frame cylinder to support the cab. This
support sleeve can be obtained from
TEREX | Fuchs.
4.11.2 During operation
Only enter or leave the cab when it is in the
home position. The cab must not be moved.
The steps must only be used to enter and exit
the cab, and not as a platform. Machine opera-
tors must always take care to ensure that any
and all movements of the cab will not put
themselves or others at risk.
Serious injury due to electric
shock
• When working with the cab ele-
vated, special care must be taken
to avoid contact with overhead
power lines.
In an emergency: If the machine
touches an overhead power line, it
must only be exited or touched by
persons standing outside the cab
when it is certain that the machine
is no longer in contact with the
power line or the electricity supply
has been switched off.
h Chapter 2.2.6 Safe working with
the machine
Serious injury due to collision
• When close range cut-off (dip-
perstick) is deactivated, please
note that the distance between
the cab and the work attachment
decreases.
• When loading long and thin parts
which protrude from the loading
grab, these parts may break into
the cab if the grab swings out vio-
lently or if the close range shut-off
system is activated.
In an emergency: Administer first
aid, seek treatment from a doctor
