Terex Fuchs MHL380 D User Manual

3 TECHNICAL DATA
3.4 MHL380 D
3.2 General structure
380-0101-506
1 3 2
4
5
8
4
7
6
9
10
11
12
Fig. 8 General structure
1 Front axle (steering axle)
2
Rear axle (full floating axle)
3
Single-stage transfer gear with two variable speed
axial piston motors
4
4-point outrigger
5
Counterweight
6
Lift cylinder
7 Cab which can be raised and moved forwards
8
Cab lift mechanism
9
Boom
1
0 Dipperstick cylinder
1
1 Dipperstick
1
2 Cactus grab
