Terex Fuchs MHL380 D User Manual

CARE AND MAINTENANCE 7
MHL380 D 7.23
Item
Lubricating point
Quantity
daily
weekly
Remarks
1*
Bearing of cab which can be raised and
moved forward
24
X
Automatic central lubrication,
uppercarriage
2
Boom bearing
2
X
3
Lift cylinder bearing
4
X
4 Dipperstick bearing 2 X
5
Dipperstick cylinder bearing
4
X
6
Slewing joint (slew ring, toothing)
8
X
7
Work attachment mounting bearing
2
X
Manual lubrication
8
Cab door hinge, lock (see Fig. 175)
3
X
9 Engine hood hinge 2 X
10
Maintenance door hinge
2
X
11
Hinge on the cooler flap of the water/charge
air cooler
2
X
12
Hinge on the cooler flap of the hydraulic oil
cooler
2
13 Grease nipple on cylinder bearings 8 X Perform additional lubrication
(manual lubrication) with work
equipment lowered to the
ground (system not under pres-
sure).
14
Outrigger foot bearing
4
X
Automatic central
lubrication, undercarriage (op-
tional)
15
Outrigger leg bearing
4
X
16 Outrigger cylinder bearing (for outrigger leg) 4 X
17
Outrigger cylinder bearing (for undercarriage)
4
X
18
Steering housing bearing (see Fig. 172)
4
X
19
Steering cylinder bearing (see Fig. 173)
4
X
20
Oscillating axle bearing (see Fig. 174)
1
X
ATTENTION
* The designated points must undergo a visual and functional inspection every 500 operating
hours. Look out for general damage and wear in particular.
h Chapter 7.8.3 Maintenance and inspection plan
Defective lubrication nipples may result in bearing damage. Replace damaged lubrication nip-
ples immediately and check to ensure grease is passing through them. Following mainte-
nance work, manually lubricate a lubricating point until grease escapes.
j WARNING
Danger of injury due to falling
• Before greasing the machine, apply the outriggers and lower the loading equipment (boom
in horizontal position).
• The grab must be lubricated separately as described in the operating instructions supplied
with the grab.
In an emergency: Administer first aid, seek treatment from a doctor
