DISPLAY AND CONTROL ELEMENTS 4
MHL380 D 4.5
Control panel
MHL-NBXX-554
61
62
83
82
63
64
81
80
65
66
79
78
67 68 75 76 77
Fig.
24 Control panel
61 Pushbutton for lowering cab
6
2 Pushbutton for cab forward
6
3 Pushbutton for raising cab
6
4 Pushbutton for deactivating close range
cut-off (dipperstick)
6
5 Pushbutton for parking brake
6
6 Pushbutton for swing brake
6
7 Flashing control indicator (left)
6
8 Error display for engine control system
(Electronic Engine Control III)
7
5 Preheat display
7
6 Indicator – general warning/emergency
operation active
7
7 Flashing control indicator (right)
7
8 Pushbutton for oscillating axle lock re-
lease
7
9 Pushbutton for travel and work functions
Pushbutton function: enable work func-
tions (Pushbutton function: bypass cut-off
of work functions (emergency)
8
0 Pushbutton for hazard warning lights
8
1 Pushbutton for side lights/headlamps
8
2 Pushbutton for cab backward
8
3 Not assigned
