Set Stage - XY Offset
Index - X will index the stage as specified in the adjacent edit box. Value represents tip
movement in a Cartesian plane (although the stage actually moves). Holding down
the shift key while selecting Index – X will move the X portion of the stage to
the 0 offset position.
Index - Y will index the stage as specified in the adjacent edit box. Value represents tip
movement in a Cartesian plane (although the stage actually moves). Holding down
the shift key while selecting Index – Y will move the Y portion of the stage to
the 0 offset position.
Single Red Up Arrow will move the stage 50 steps toward the back of the
Quadra.
Single Red Down Arrow will move the stage 50 steps toward the front of the
Quadra.
Single Red Left Arrow will move the stage 50 steps left relative to one facing
the front of the Quadra.
Single Red Right Arrow will move the stage 50 steps right relative to one facing
the front of the Quadra.
Home Stage - XY will reset the XY position to the center of the stage. This is
useful in the event that the XY portion of the stage has lost its true position,
perhaps due to a physical collision.
Stage Formatting
Select the button to move to the desired Quadrant.
WARNING: Stage indexing will occur at its current height. Make sure
that the plate has sufficient clearance of the tips and the stage is not
completely below the shuttle.
