Quadra 4 Operator Manual
Tomtec
33
everybody finds their own best way, a starting point is to step the protocol through the
entire program, step-by-step using the simple Quadra programming features. It
provides a visual presentation of the program as you proceed.
The program allows you to assign a descriptive name to each plate, reservoir, or rack of
tips. This aids in tracking the program. As each new device is placed on the shuttle, use
the shuttle layout icon to bring the appropriate database values. At the end, it is
essential that you record the starting location of each microplate, reservoir, or tip
rack in their respective stackers. This information may be recorded in an initial pause
statement.
Tomtec personnel are available to assist you in creating a stacker program.
When using this program for the first time check that:
1. The Calibration Height is set on all fixtures in use. These values can be set in the
Database Editor. Open the Quadra DBEditor by selecting Database → ‘Edit Plate,
... Database.’
2. The COM Port setting is correct. This can be set by going to the Options Menu →
Quadra → Configure COM Ports.
3. The proper machine model is selected. This can be set by going to the Options
Menu → Quadra → Configure Model.
Upon Connecting to the Quadra for the first time, the program will automatically
recognize the head configuration, and change its settings accordingly. Make sure,
before you start writing your protocol, that you have Configure Model set to the
right configuration, or simply connect to the machine before programming.
1.3.1 Preparing the Quadra to run a program:
1. Click the ‘Connect’ button on the Main Toolbar to establish the serial connection with
the Quadra.
2. After the connect operation is successful, the ‘Initialize’ button will enable. Click this
button to initialize the Quadra.
3. Be sure to include the proper fixtures on the shuttle layout before adding steps to
your program.
