Quadra 4 Operator Manual
Tomtec
77
3.27 Shuck Tips
Shuck Tips removes disposable tips from the tip pins or removes fixed tip assembly
from the tip head.
Conditions
To Shuck Tips, select a shuttle position that has a tip capable fixture.
Remarks
Shuck Tips
Sets the function to shuck tips from the selected shuttle position.
Cycle Pinch Tubes
When checked, the pinch tube will open before the tips are shucked, and close after the
stage is lowered. This feature is available on pumps with pinch tubes.
The Shuck Tips function can also be used to unload an SPE Pressure block if there is
an SPE Block currently loaded. In this case the “Shuck Tips” verbiage will be replaced
by “UnLoad SPE”.
3.28 Shuttle Layout Change
Allows the user to pause the program that is running, and change the fixtures
and components loaded onto the shuttle.
