Quadra 4 Operator Manual
Tomtec
118
6.7 Miscellaneous
Magnet Device
On/Off is used to turn the magnet on or off for the selected Magnet Nest.
Shaker Device
On/Off is used to turn shaking on or off for the selected Shaker Nest.
Set Air Pressure
Start Monitoring will continuously monitor and display the air pressure. The
button text will change to Stop Monitoring once selected. Selecting the button then
will stop the continuous monitoring.
Note: The air pressure is changed by turning the black gauge knob on the side of
the Quadra.
Important Note:
Powered accessories such as Vacuum Trap and Shaker Nests, should not be
connected with the Quadra 4 powered on. Please turn off AC power BEFORE
connecting these accessories.
