Quadra 4 Operator Manual
Tomtec
117
Filter Control
Start Filtering will turn on the vacuum to the auto-vacuum box.
Stop Filtering will turn off the vacuum to the auto-vacuum box.
Mini-Trap:
Vacuum Control
Set Vacuum will set the vacuum in inches.
Get Vacuum displays the current vacuum setting in inches.
Refresh Vacuum does a quick vacuum set to the value displayed in the edit box.
Vac Off turns off the vacuum to the vacuum box.
Vac On turn on the vacuum to the vacuum box.
Important Note:
Powered accessories such as Vacuum Traps, Autotraps and Shaker
Nests, should not be connected with the Quadra 4 powered on. Please
turn off AC
power
BEFORE
connecting these accessories.
