The “AVG % ERROR” on the spreadsheet for the SET VOLUMES run in the
“VERIFICATION OF THE CALIBRATION CURVE” procedure MUST fall within the
AVERAGE % ERROR range listed in the chart below:
SET VOLUME AVERAGE % ERROR
10.0L to 49.9L
≤ 5.0%
50.0L to 99.9L
< 3.0%
100.0L to 450.0L
< 2.0%
If any SET VOLUME fails the VERIFICATION, redo the “CALIBRATION CURVE”
procedure and repeat the “VERIFICATION OF THE CALIBRATION CURVE” procedure.
10.0 “Calibration Template” For the Verification Curve
Open the “Step 4 Verification Data” and at the top of the spreadsheet fill in the
following information:
TODAY’S DATE
TIME
TEMP º C (To nearest 0.2ºC)
HUMIDITY % (To nearest 10%)
BAROMETRIC PRESSURE (In. Hg)
HEAD SERIAL NUMBER
Fill in the tare weight of each weighing Verification Vessel in the area marked
“TARE WT.”.
