3.34 Vacuum Box Operation
The vacuum box operation is used to control the automated vacuum box.
Conditions
None
Remarks
Open Vacuum Box performs vacuum off, tray down, open box, and then tray
up. If Run Raw is checked then the box will just open.
Close Vacuum Box performs vacuum off, tray down, and then close box. If Run Raw is
checked then the box will just close.
Turn On Vacuum performs vacuum off and then raises or lowers the tray (as indicated
by the checkbox) before turning on the vacuum. If Run Raw is checked then the
vacuum will just turn on.
Turn Off Vacuum performs vacuum off and then raises or lowers the tray (as indicated
by the checkbox). If Run Raw is checked then the vacuum will just turn off.
Raise Tray performs vacuum off and then raises the tray. If Run Raw is checked then
the tray will just raise (Warning: It is not recommended to raise the tray while vacuum is
on).
