Operation
Topcon HiPer+ Operator’s Manual
4-22
1. Connect your receiver and computer. See “Connecting the
HiPer+ and a Computer” on page 2-5 for this procedure.
2. Click on Help->About (Figure 4-16).
Figure 4-16. Help->About
The About PC-CDU dialog box opens (Figure 4-17).
Figure 4-17. About PC-CDU
About PC-CDU lists important information about the
different hardware accessories and software properties. This
list includes the following, which you will need if you
contact TPS or your dealer:
• Receiver model
• Receiver ID
• Firmware version
3. When finished, click OK, then click File->Disconnect to
prevent conflicts with serial port management.
