Topcon HiPer Plus - Connector Specifications; Radio (Modem) RF Connector

Specifications
Topcon HiPer+ Operator’s Manual
B-10
NOTICE
Use robust checking procedures in areas of
extreme multipath or under dense foliage.
Connector Specifications
This section lists HiPer+ connector details.
Radio (Modem) RF Connector
The Pacific Crest PDL (UHF) modem connector type
(Table B-2) is a BNC Bulkhead Jack RF connector with an
Applied Engineering Product part number of 6501-7051-003.
Spread Spectrum modem (TPS) or GSM modem connector
type (Table B-3) is a TNC RF connector.
Table B-2. Pacific Crest PDL (UHF) Modem Connector Specifications
Type Signal Name Dir Details
BNC Modem I/O I RF input from PDL antenna
Table B-3. Spread Spectrum/GSM Modem Connector Specifications
Type Signal Name Dir Details
TNC Modem I/O I/O RF input from modem
antenna
