Operation
Topcon HiPer+ Operator’s Manual
4-26
7. Click Get from Device for device information
(Figure 4-21 on page 4-25).
8. Select the Program tab and set the Capture Method to
Soft Break Capture (recommended) (Figure 4-22).
Figure 4-22. Program Tab Settings
9. Browse for and select the Power board’s RAM file
(Figure 4-22).
10. Click Load and wait until 100% of the power board file
loads into your receiver.
NOTICE
If you selected an incorrect RAM file, an error
message displays at the bottom of the dialog
box. Reselect the correct file.
11. Click File->Exit.
12. Clear the receiver’s NVRAM (see “Clearing the
NVRAM” on page 4-18) and update the almanac (see
“Collecting Almanacs” on page 2-49) after loading new
firmware.
