Loading New Firmware
1-866-4TOPCON www.topconpositioning.com
4-25
3. Select the Program tab and set the Capture Method to
Soft Break Capture (recommended) (Figure 4-20).
Figure 4-20. Program Tab Settings
4. Browse for and select the receiver board’s RAM file and
Flash file (Figure 4-20).
5. Click Load and wait until 100% of the files load into
your receiver.
NOTICE
If you selected an incorrect RAM or Flash file,
an error message displays at the bottom of the
dialog box. Reselect the correct file.
6. Select the Device tab and set the Device Type as
Receiver’s Power Board (Figure 4-21).
Figure 4-21. Set Device Type
