Chapter 3
1-866-4TOPCON www.topconpositioning.com
3-1
Setup and Survey
This chapter describes:
•HiPer+ setup
• RTK Base station setup
• RTK Rover setup
• Basic surveying with the HiPer+
Your HiPer+ can be used as a Rover station or a Base station with
an optional external radio.
HiPer+ Receiver Setup
To set up your HiPer+ receiver, you must:
1. Configure the receiver as shown in Chapter 2.
2. Set up your Base or Rover station. See “Set up HiPer+
Receiver” on page 3-2
3. Measure the antenna height. See “Measure Antenna Height”
on page 3-2.
4. Begin collecting data. See “Collect Data” on page 3-4.
All HiPer+ receivers include an internal, micro-strip antenna.
This antenna is able to capture L1/L2 signals from GPS and
GLONASS satellites.
