Appendix A SCPI Command Reference
CONFigure subsystem
304 WCDMA Options Version 6.20
:CONFigure:WCDMa:NB:LEVel:PSCH
:CONFigure:WCDMa:NB:LEVel:PICH
:CONFigure:WCDMa:NB:LEVel:AICH
:CONFigure:WCDMa:NB:LEVel:OCNS
Syntax
:CONFigure:WCDMa:NB:LEVel:PSCH <Real1>
Parameters
Real1 is a floating point real number. The minimum value is -35, the maximum
value is 0. The minimum resolution is 0.1. The default value is -3.0.
Description
This command sets the PSCH power relative to CPICH or Ior, depending on what is set
with CONF:WCDM:LEV:REL.
Query
The query form of this command will return the current setting of the Willtek 4400.
Example
:CONF:WCDMA:NB:LEV:PSCH -12
:CONF:WCDMA:NB:LEV:PSCH?
Value returned in this example: -12
.
Syntax
:CONFigure:WCDMa:NB:LEVel:PICH <Real1>
Parameters
Real1
is a floating point real number. The minimum value is -35, the maximum
value is 0. The minimum resolution is 0.1. The default value is 0.0.
Description
This command sets the PICH power relative to CPICH or Ior, depending on what is set
with CONF:WCDM:LEV:REL. Also this parameter range depends on the setting
from CONF:WCDM:LEV:REL. Its minimum is -35.0 in case that it is relative to
Ior. If it is relative to CPICH, however, then it is -10.0.
Query
The query form of this command will return the current setting of the Willtek 4400.
Example
:CONF:WCDMA:NB:LEV:PICH -16
:CONF:WCDMA:NB:LEV:PICH?
Value returned in this example:
-16.
Syntax
:CONFigure:WCDMa:NB:LEVel:AICH <Real1>
Parameters
Real1
is a floating point real number. The minimum value is -35, the maximum
value is 0. The minimum resolution is 0.1. The default value is -0.6.
Description
This command sets the AICH power relative to CPICH or Ior, depending on what is set
with CONF:WCDM:LEV:REL.
Query
The query form of this command will return the current setting of the Willtek 4400.
Example
:CONF:WCDMA:NB:LEV:AICH -17
:CONF:WCDMA:NB:LEV:AICH?
Value returned in this example:
-17.
Syntax
:CONFigure:WCDMa:NB:LEVel:OCNS <Real1>
Parameters
Real1 is a floating point real number. The minimum value is -35, the maximum
value is 0. The minimum resolution is 0.1. The default value is -5.0.
