Appendix A SCPI Command Reference
MEASure subsystem
346 WCDMA Options Version 6.20
:MEASure:WCDMa[:CONTinuous]:UEReport:CPICh:ECNO
:MEASure:WCDMa[:CONTinuous]:UEReport:CPICh:RSCP
:MEASure:WCDMa[:CONTinuous]:UEReport:PLOSs
Query
The query form of this command starts the measurements and - after all 6 measure-
ments have been completed and all measurement results obtained - delivers a string,
containing 6 measurement result values, separated with commas. The order and type
of these measurement result values delivered back is as follows:
1. CPICh ECNO, floating point real number representing UE measured normalized
chip energy per noise value of the P-CPICH,
2. CPICh RSCP, floating point real number representing UE measured received sig-
nal code power of the P-CPICH,
3. PLOSs, floating point real number representing the pathloss between Node-B and
UE, estimated by the UE,
4. TXPower, floating point real number representing the UE transmit power,
5. RTTDifference, floating point real number representing UE measured RX-
Time-Difference between UL and DL signal,
6. TRCH BLER, floating point real number representing the UE estimated BLER
value for the Transport Channel defined with CONFigure:WCDMa:MEA-
Sure:UEReport:TRCH.
Note: For a further description of the single measurements, see description of the
related commands below.
Example
:MEAS:WCDM:UER:ALL?
All UE Report measurements will be performed in a sequence, e.g.
23,85,102,97,992,3.
Syntax
:MEASure:WCDMa[:CONTinuous]:UEReport:CPICh:ECNO
Parameters
There are no parameters.
Description
Reports the UE measured normalized chip energy per noise value of the P-CPICH.
Query
The query form of this command will return a string containing the floating point
value with the result.
Example
:MEAS:WCDM:UER:CPICh:ECNO?
Starts the measurement and returns the result, e.g.
31.
Syntax
:MEASure:WCDMa[:CONTinuous]:UEReport:CPICh:RSCP
Parameters
There are no parameters.
Description
Reports the UE measured received signal code power of the P-CPICH.
Query
The query form of this command will return a string containing the floating point
value with the result.
Example
:MEAS:WCDM:UER:CPICh:RSCP?
Starts the measurement and returns the result, e.g.
41.
Syntax
:MEASure:WCDMa[:CONTinuous]:UEReport:PLOSs
Parameters
There are no parameters.
