Appendix A SCPI Command Reference
MEASure subsystem
348 WCDMA Options Version 6.20
:MEASure:WCDMa:ARRay:RFTX:POWer:MEAN
:MEASure:WCDMa:ARRay:RFTX:POWer:PEAK
:MEASure:WCDMa:ARRay:RFTX:NSTair[:DATa]
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Performs the frequency error measurement as many times as specified.
Query
The query form of this command will perform the measurement the specified number
of times and return the results.
Example
:MEAS:WCDM:ARR:RFTX:FREQ? 5
Starts five measurements, the results of which are returned.
Example:
47.1,91.5,13.6,-4.8,15.3.
Syntax
:MEASure:WCDMa:ARRay:RFTX:POWer:MEAN <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
This command starts a continuous array measurement of the mobile's output power
specified by number of arrays <Int1>. To read out the entire measurement results
array use the command FETCh:WCDMa:RFTX:POWer:MEAN.
Query
This query command will perform the measurement the number of times specified by
<Int1>. As soon as all measurements have been completed, all result values will be
returned. The values delivered will contain Int1 floating-point numbers in dBm.
Example
:MEAS:WCDM:ARR:RFTX:POW:MEAN? 10
Starts ten measurements, the results of which are returned.
Example: 47.1,91.5,13.6,-4.8,15.3,37.1,51.5,33.6,-4.4,55.3
Syntax
:MEASure:WCDMa:ARRay:RFTX:POWer:PEAK <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
This command starts a continuous array measurement of the mobile's peak output
power specified by number of arrays <Int1>. To read out the entire measurement
results array use the command FETCh:WCDMa:RFTX:POWer:PEAK.
Query
This query command will perform the measurement the specified number of
<Int1>. As soon as all measurements have been completed, all result values will be
returned. The values delivered back will contain <Int1> floating-point numbers in
dBm.
Example
:MEAS:WCDM:ARR:RFTX:POW:PEAK? 10
Syntax
:MEASure:WCDMa:ARRay:RFTX:NSTair[:DATa]
Parameters
There are no parameters.
