Appendix A SCPI Command Reference
MEASure subsystem
352 WCDMA Options Version 6.20
:MEASure:WCDMa:ARRay:RFTX:MODQuality:RHO
:MEASure:WCDMa:ARRay:RFTX:MODQuality:IQOFfset
:MEASure:WCDMa:ARRay:RFTX:MODQuality:IQIMbalance
:MEASure:WCDMa:ARRay:RFTX:INNErloop
Syntax
:MEASure:WCDMa:ARRay:RFTX:MODQuality:RHO <Int1>
Parameters
Int1 is an integer. The minimum value is 0, the maximum value is 100. The default
value is 0.
Description
Starts a continuous closed loop measurement.
Query
The query form of this command will return a floating point value.
Example
:MEAS:WCDM:ARR:RFTX:MODQ:RHO? 5
Syntax
:MEASure:WCDMa:ARRay:RFTX:MODQuality:IQOFfset <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Performs an origin offset vector error measurement as many times as specified.
Query
The query form of this command will perform the measurement the specified number
of times, and return the results.
Example
:MEAS:WCDM:ARR:RFTX:MODQ:IQOF? 10
Syntax
:MEASure:WCDMa:ARRay:RFTX:MODQuality:IQIMbalance <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Performs an IQ imbalance vector error measurement as many times as specified.
Query
The query form of this command will perform the measurement the specified number
of times, and return the results.
Example
:MEAS:WCDM:ARR:RFTX:MODQ:IQIM? 10
Syntax
:MEASure:WCDMa:ARRay:RFTX:MODQuality:IQIMbalance <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
It starts inner loop power control measurements and it returns an array of Int1
measurements values as well as the TPC step error for each step.
Query
The query form of this command will perform the measurement Int1 and return the
results values as well the error values. The result delivered will contain an array of
floating point numbers.
Example
:MEASure:WCDMa:ARRay:RFTX:INNErloop? 10
