6.3.3 Main bearing shell - install
Periodicity
Description
Working hours 90 000
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 2.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate 3
Support equipment
Description Part No. CSN QTY
Spur-geared chain block 94017-2.5-5.4 2
Shackle (WLL 2000 kg) 94019G 1
Lifting plate 94119 1
Turning-out device 94118B 1
Lifting tool - bearing shell 94116A 1
Dial gauge N/A 1
Hydraulic ram 94936 3
HP oil pump 94931 1
Pressure gauge 94934A 1
Steel beam N/A 1
Steel plate N/A 1
Bracket 94141 1
Supplies
Description QTY
Molykote paste G A/R
Engine oil A/R
Spare Parts
Description Part No. CSN QTY
Bearing shell 1
SAFETY PRECAUTIONS
WARNING
Injury and Damage Hazard: Do not turn the crankshaft when the platforms, tools and/or
supports, are installed. This will cause injury to personnel and damage to equipment.
