8.5.7 Connecting rod - install the bottom end bearing
Periodicity
Description
Working hours 70 000
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 2.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic AR
Support equipment
Description Part No. CSN QTY
Spur-geared chain block 94017-2.5-6-5 1
Lever chain hoist 94016-3.2-5.5 1
Lever chain hoists 94016-2.5-5.5 2
Eye bolt 94045-M24 4
Eye bolt 94045-M10 1
Shackle 94019K 1
Shackle 94019L 4
Shackle 94019P 2
Sling 94038-015 1
Deviation pipe 94117B 1
Chain 94327 1
Console frame 94326 1
Support 94322 1
Support 94322A 1 or 2
Supplies
Description QTY
Oil A/R
Steam engine cylinder oil, ISO VG 1000/1500 A/R
Spare Parts
Description Part No. CSN QTY
Bearing shell - crank pin 1
Bearing shell - crank pin 1
