13.4.2 HP pilot fuel pipe - install
Periodicity
Description
Unscheduled
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 1.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic AR
Support equipment
Description Part No. CSN QTY
Torque wrench 94014 1
Supplies
Description QTY
Oil A/R
Never Seez NSBT8 A/R
Spare Parts
Description Part No. CSN QTY
Pilot fuel pipe 1
Pilot fuel pipe 1
Pilot fuel pipe 1
O-ring type FKM A/R
O-ring type FKM A/R
SAFETY PRECAUTIONS
CAUTION
Damage Hazard: Make sure that you do not cause damage to the sealing faces or the
pilot fuel pipes. Do not apply lateral force to the pilot fuel pipes and the flanges.
PRELIMINARY OPERATIONS
• None
X62DF
AA00-8790-00AAA-720A-A
Maintenance Manual HP pilot fuel pipe - install
Winterthur Gas & Diesel Ltd.
- 768 - Issue 002 2020-10
