7.5.5 Cylinder cover - install
Periodicity
Description
Unscheduled at each piston removal
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 2.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate AR
Support equipment
Description Part No. CSN QTY
Lifting tool 94215 1
Pre-tensioner 94215A 10
Cylinder cover support 94266 1
Hydraulic unit 94942 1
Pressure gauge 94934A 1
HP hose 94935 1
Flexible hose 94935A 10
Lifting tool 94265 1
Supplies
Description QTY
Oil A/R
Spare Parts
Description Part No. CSN QTY
Cylinder cover 1
O-ring 1
O-ring 1
SAFETY PRECAUTIONS
CAUTION
Injury Hazard: Use the correct equipment to lift and move the cylinder cover.
PRELIMINARY OPERATIONS
• None
X72DF
AA00-2708-00AAA-720A-A
Maintenance Manual Cylinder cover - install
Winterthur Gas & Diesel Ltd.
- 252 - Issue 002 2020-10
