7.5 Cylinder cover
7.5.1 Cylinder cover - remove
Periodicity
Description
Unscheduled at each piston removal
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 4.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate AR
Support equipment
Description Part No. CSN QTY
Lifting tool 94215 1
Pre-tensioning jacks 94215A 10
Cylinder cover support 94266 1
Hydraulic unit 94942 1
Pressure gauge 94934A 1
HP hose 94935 1
Flexible hose 94935A 10
Lifting tool 94265 1
Supplies
Description QTY
None
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
WARNING
Injury Hazard: You must put on safety goggles and gloves when you do work on hot
components. Oil can come out as a spray and cause injury.
CAUTION
Injury Hazard: Use the correct equipment to lift and move the cylinder cover.
X62DF
AA00-2708-00AAA-520A-A
Maintenance Manual Cylinder cover - remove
