WinGD X62DF - End View (Generic, Seen from the Driving End)

Fig 1-2 End view (generic, seen from the driving end)
FS
ES
001
002
003
005
004
Legend
ES Exhaust side FS Fuel side
001 Turbocharger 004 Supply unit
002 Auxiliary blower 005 Rail unit
003 Flywheel
