8.5 Connecting rod
8.5.1 Connecting rod - prepare before removal
Periodicity
Description
Working hours 70 000
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 1.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate 2
Support equipment
Description Part No. CSN QTY
Shackles 94018A 4
Lever chain hoists 94016-1-2.5 2
Connecting rod tool 94334 1
Stop plate 94335 1
Eye bolt 94045-M30 1
Supplies
Description QTY
Molyslip copaslip A/R
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
WARNING
Before you operate the turning gear, make sure that no personnel are near the flywheel.
PRELIMINARY OPERATIONS
• The engine must be stopped and made safe for maintenance, refer to section 4.1 Do
maintenance work - general procedure
