13.3.3 HP fuel pipe (fuel rail to injection valve) - grind the sealing face
Periodicity
Description
Unscheduled
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 0.5 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate 1
Support equipment
Description Part No. CSN QTY
Grinding tool 94871 1
Stencil 94871A 1
Hand drill NA 1
Supplies
Description QTY
Emery paper (different grades) AR
Polishing cloth AR
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
• None
PRELIMINARY OPERATIONS
• The HP fuel pipe must be removed, refer to section 13.3.2 HP fuel pipe (fuel rail to
injection valve) - remove
X62DF
AA00-8733-00AAA-655A-A
Maintenance Manual HP fuel pipe (fuel rail to injection valve) - grind the sealing face
Winterthur Gas & Diesel Ltd.
- 744 - Issue 002 2020-10
