16 If necessary, operate the chain block (004) to move the connecting rod (003).
Fig 8-33 Bottom end bearing
17 Loosen the screws (003, Figure 8-34).
18 Remove the four bolts (004).
19 Remove the two supports (002 and or 005).
20 Remove the lever chain hoist from the connecting rod.
X62DF
AA00-3303-03AAA-720A-A
Maintenance Manual Connecting rod - install the bottom end bearing
Winterthur Gas & Diesel Ltd.
- 414 - Issue 002 2020-10
