7.1.2 Cylinder liner - remove
Periodicity
Description
Unscheduled As necessary
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 2.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate AR
Support equipment
Description Part No. CSN QTY
Eye bolt 94045-Mxx 2
Sling 94049A 2
Shackle 94018D 2
Lifting tool 94201 1
Plate 94201B 2
Lifting tool 94201A 2
Sling 94039-x-x 2
Supplies
Description QTY
Molyslip Copaslip A/R
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
• None
PRELIMINARY OPERATIONS
• The engine must be stopped and made safe for maintenance, refer to section 4.1 Do
maintenance work - general procedure
• The cylinder cover must be removed, refer to section 7.5.1 Cylinder cover - remove
• The lubricating quills must be removed, refer to section 7.2.1 Lubricating quill - remove
• The piston must be removed, refer to section 8.7.3 Piston - remove
• For a DF engine - the gas admission valves must be removed, refer to section 7.3.2 Gas
admission valve - remove
X72DF
AA00-2124-00AAA-520A-A
Maintenance Manual Cylinder liner - remove
Winterthur Gas & Diesel Ltd.
- 172 - Issue 002 2020-10
