8.5.10 Connecting rod - install
Periodicity
Description
Working hours 70 000
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 10.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic AR
Support equipment
Description Part No. CSN QTY
Deviation pipe 94117B 1
Shackle 94018C 1
Spur-geared chain block 94017-2-4-3 4
Shackles 94018E 4
Chain (symmetrical) 94019A 1
Tool, connecting rod
assembly
94334A 1
Chain (asymmetrical) 94019B 1
Supplies
Description QTY
None
Spare Parts
Description Part No. CSN QTY
Connecting rod 1
SAFETY PRECAUTIONS
WARNING
Injury Hazard. Before you operate the turning gear, make sure that no personnel are near
the flywheel, or in the engine.
WARNING
Injury Hazard. To prevent injury, be careful when you move the connecting rod.
PRELIMINARY OPERATIONS
• None
