NOTE: If necessary, replace the flaps, refer to the related procedures.
6 Remove the pins (001 and 004, Figure 11-1) from the locked position.
7 Close the covers (002, 003).
8 Put the pins (001, 004) in their stowage positions.
Fig 11-2 Level switches and filters
II - II
001
002
003
004
005
006
007
008
009
010
001
00860
IV
CLOSE UP
• None
X72DF
AA00-6420-00AAA-310A-A
Maintenance Manual Scavenge air receiver - examine
Winterthur Gas & Diesel Ltd.
- 627 - Issue 002 2020-10
