WinGD X62DF - Starting Air Valve - Preparation

PROCEDURE
1 Make sure that the pressure in the starting air system is released.
2 Remove the air pipe (002, Figure 7-48) from the starting air valve (001).
Fig 7-48 Starting air valve - preparation
00709
002
001
3 Disconnect the electrical connection from the 3/2-way solenoid valve (002, Figure 7-49).
4 Remove the screws (003).
5 Carefully remove the starting air valve from the cylinder cover (004).
6 Remove and discard the gasket (006).
7 If necessary remove the pipe (005).
8 Put protection over the opening in the cylinder cover (004).
X62DF
AA00-2728-00AAA-520A-A
