Fig 8-75 Piston - assemble (example)
001
002
003
004
005
006
007
008
009
010
011
012
013
10 Attach the hydraulic unit, the pressure gauge, the distributing piece and the flexible
hoses.
11 Install the round nuts to the elastic studs in the sequence given, refer to section 4.2
Tighten a round nut with a pre-tensioner.
CLOSE UP
• None
X72DF
AA00-3403-00AAA-710A-A
Maintenance Manual Piston - assemble
Winterthur Gas & Diesel Ltd.
- 496 - Issue 002 2020-10
